МедСаніСтар
Access Station
Disinfection access station for check body temperature and sanitize hand using special liquid. Best solution for access control and COVID protection

The MedSaniStar is a smart hygiene checkpoint designed to ensure safe and contactless health control in public and business environments. Combining advanced body temperature detection and automatic hand disinfection in a single unit, it offers an efficient solution to protect employees, customers, and guests from viral threats. This device includes a facial recognition system, mask detection, real-time body temperature screening, and integrated hand sanitization. The built-in access control relay allows entry only to individuals with a normal temperature. The premium Grand model provides cloud-based visitor logging and temperature reporting.

Face Recognition and Contact-Free Temperature Sensing

The device is equipped with an advanced face recognition system and temperature detection sensor, ensuring high-speed and accurate screening.

Comprehensive Safety with MedSaniStar


MedSaniStar features a touch-free infrared thermal scanner paired with intelligent face recognition and mask detection.


It delivers immediate temperature readings and initiates automatic hand disinfection. The system also connects to a remote server for temperature data recording and can control automated door access, making it ideal for offices, stores, clinics, gyms, and public venues.

Why Choose MedSaniStar?


  • Early detection of elevated body temperature or flu-like symptoms in staff and visitors.
  • Fast, contactless temperature measurement using a precision thermal sensor.
  • Access control integration via relay that restricts entry based on body temperature.
  • Automatic temperature report generation, with cloud (iCloud) storage and Telegram alert bot.
  • Built-in hand sanitizer with automatic dispensing of disinfecting liquid.
  • Software update support for long-term performance and security.
  • Modular upgrade options to meet evolving health protocols.

Technical specifications of the recognition system:


  • 8-inch IPS LCD vandal-resistant screen
  • Face database supports up to 30,000 individuals
  • Fast recognition within 1 second with ~97% accuracy
  • Mask-wearing face detection support
  • Industrial-grade binocular camera with infrared night vision and LED illumination
  • High-performance processing using Rockchip RK3288 quad-core CPU
  • Integrated Heimann thermal sensor for temperature reading
  • Optimal detection distance: 0.5 meters; maximum range: 1 meter
  • Temperature accuracy: ±0.5°C
  • Screening takes just seconds, with visual alerts and external red light for abnormal readings
  • Measurement process captured via photo logging
  • Power: 12V (adapter for 110–220V included)
  • Interfaces: USB, Relay, RJ45 (Ethernet), Wiegand 26/34, Wi-Fi

Технічна специфікація


Висота:1940mm/76.4”
Ширина:130mm/5.1” with legs 500mm/19.7”
Довжина:560mm/22” Weight 75kg/165LB
Power supply:230V/50Hz or 120V/60Hz
Power consumption:0.3kW
Touch screen:10.1”
Infared temperature sensor
Face and mask recognition
10L container for disinfection liquid
4L drain container
Grand model-glass exterior depends on version
